Unofficial Patch Tuesday – MSMQ Privilege Escalation Vulnerability Hotfix

Executive Summary

This security patch resolves a public vulnerability in the Windows Message Queuing Service (MSMQ) discovered by KoreLogic [1]. By default, the Message Queuing component is not installed and only Windows XP is affected. Since Microsoft stopped releasing security patches for Windows XP [2] and an exploit module is available in Metasploit [3], We have decided to release a Hotfix for this vulnerability to protect Windows XP users. The patch has been successfully tested on Windows XP SP3 and doesn't contain any malicious content.

UPDATE: The original version of the patch is not compatible with the /3GB boot parameter. The current version is compatible with the /3GB boot parameter. We would like to thanks to Mr. Patrik Horník from technology news site for reminding.

Microsoft doesn't plan to patch this vulnerability (from KoreLogic advisory):


How to apply a patch

1. Boot Windows XP in Safe mode [4]
2. Run python script(patch) [5]


# MSMQ Privilege Escalation Vulnerability Hotfix - CVE-2014-4971
# 12th August 2014 - Alino from Citadelo -
# Disclaimer: Use this security patch at your own risk.
import os
import sys
import ctypes
import shutil
import hashlib
import platform
original = "7849c06480eeb96c0d06689e5db80ddcacc5dd077ce6dfa25ccb7bdf3378c962"
patched = "b014b913a1f913fad4d15cce9b27ff2b54f6f015c768b622c2baf049ca5f5b2e"
old_patch = "f481a1c6ea8508854ee8b4051d423679d58abb66586d904c7240b200fb109432"
driver = os.environ['WINDIR'] + "\\System32\\drivers\\mqac.sys"
driver_bck = os.environ['WINDIR'] + "\\System32\\drivers\\mqac.bck"
print "\n[*] MSMQ Privilege Escalation Vulnerability Hotfix - CVE-2014-4971"
print "[*] 12th August 2014 - Alino from Citadelo -"
if platform.release() != "XP":
    sys.exit("\n[-] ERROR: This patch is for Windows XP!")
if ctypes.windll.user32.GetSystemMetrics(67) == 0:
    sys.exit("\n[-] ERROR: Must be run in Safe mode!")
if ctypes.windll.shell32.IsUserAnAdmin() != 1:
    sys.exit("\n[-] ERROR: You must have Administrator rights!")
if not os.path.exists(driver):
    sys.exit("\n[-] ERROR: Driver mqac.sys not found!")
hasher = hashlib.sha256()
with open(driver, "rb") as file:
    buffer =
if hasher.hexdigest() == patched:
    sys.exit("\n[-] ERROR: Already patched!")
if hasher.hexdigest() != original:
    if hasher.hexdigest() != old_patch:
        sys.exit("\n[-] ERROR: Wrong driver version! This patch is for version")
shutil.copyfile(driver, driver_bck)
print "\n[*] Backup file mqac.bck created"
buffer = buffer[:0x138] + "\x0A\xE1\x01" + buffer[0x13B:] # PE CHECKSUM
buffer = buffer[:0x1EFA] + "\xE9\xDD\x18\x01\x00" + buffer[0x1EFF:] # JMP mqac!_alldiv+0x6
buffer = buffer[:0x1F32] + "\xEB\xC6" + buffer[0x1F34:] # JMP mqac!AC2QM+0x20
buffer = buffer[:0x137DC] + "\xE8\x00\x00\x00\x00\x5B\x8B\x5B\x73\x8B\x1B\x3B\xF3\xBB\x00\x00\x00\x00\x0F\x83\xE2\xE7\xFE\xFF\xE9\x3B\xE7\xFE\xFF" + buffer[0x137F9:] # CALL mqac!_alldiv+0xb; POP EBX; MOV EBX,DWORD PTR [EBX+73h]; MOV EBX,DWORD PTR [EBX]; CMP ESI,EBX; MOV EBX,0; JNB mqac!AC2QM+0xfc; JMP mqac!AC2QM+0x5a
f = open(driver , "wb")
print "[*] Driver sucessfully patched!"

Metasploit module will fail with patched driver:



Use this security patch at your own risk.

Stay secure,
